Who doesn’t need a place to set your beverage when you’re in a heated game of cornhole? And if you’re anything like me then you’re terrible at keeping score. I bring to you the cornhole scoreboard and drink holder. But really, this thing is pretty handy.

For sneak peeks of our upcoming projects be sure to follow me on Facebook and Instagram. Also, follow me on Pinterest to get tons of projects plans from all around the web!

DIY Cornhole Scoreboard Plans - Rogue Engineer 4

Disclosure: The links provided in the “materials” and “required tools” sections are affiliate links. If you would like to support our site and help keep our content free come find out more about how we can make money with no extra cost to you.

How to Build a Corn Hole Scoreboard with Drink Holder

Step 1: Cut the Boards

The scoreboard is made of 2 boards cut at 10-1/4″ wide by 42″ long. This can be a done using a table saw.

Step 2: Cut the Feet

I measured 2″ in from the sides and bottom for a cut out to create the feet. I used a roll of tape to create the curve for the corners.

DIY Corn Hole Scorboard - Rogue Engineer 1

Step 3: Cut out the Cup Holders

Cut two boards at 4″ x 10-1/4″ and one at 1-1/2″ x 4″ for the vertical support.

Then mark the cut outs for the drink holders (about 3″ in diameter) on one board and round off the corners. Once I started cutting I decided to round them vs the 45 shown below. I also added a slot for a wine glass which wasn’t really necessary since the opening for the drink was so wide already.

DIY Corn Hole Scorboard - Rogue Engineer 2

Step 4: Drill the Holes

I drew straight lines down one of the boards, spaced equally from the sides. Then I found center, marked it on each line and spaced 22 holes 1-1/2″ apart. Find the right drill bit for the tees you are using. Practice on a scrap piece of wood to make sure you’re happy with the fit.

DIY Corn Hole Scorboard - Rogue Engineer 3

Step 5: Assemble the Drink Holder

First, I drilled pocket holes on the underside of the top and bottom boards used for the drink holder.

DIY Corn Hole Scorboard - Rogue Engineer 4

Then, with I glued and nailed it together with 1-1/4″ brad nails.

DIY Corn Hole Scorboard - Rogue Engineer 5

Step 6: Finish and Assemble

I started off by painting where the two stripes would go with yellow exterior paint. Then I taped off straight lines centered over the holes with 2″ painters tape and painted the boards and drink holder blue.

Then, once the paint was dry, I installed the drink holder using 1-1/4″ pocket screws.

DIY Corn Hole Scorboard - Rogue Engineer 6

Next I added 1″ white adhesive numbers to the board in between each hole.

DIY Corn Hole Scorboard - Rogue Engineer 7

Finally, I installed the hinges to the inside of the boards. If I had to do it over again I would have attached the drink holder last to make the hinge installation a little easier. With the drink holder on the boards wont lay flat.

DIY Corn Hole Scorboard - Rogue Engineer 8

Get the full cornhole board plans here.

DIY Cornhole Board Plans - Rogue Engineer 1



Questions? Comments?

As always, if you have any questions don’t hesitate to comment below and especially don’t forget to post pictures of your finished products in the comments! ENJOY!
